Monaco Cayman 2006 - Gauges

214 • Section 9 — Electrical Systems - Chassis Cayman 2006
Left Turn:
Left turn indicator circuits active.
High Beam:
High beams are on when illuminated.
Right Turn:
Right turn indicator circuits active.
Wait to Start:
Monitors the intake air heater and intake manifold temperature.
Low Fuel:
Fuel level in fuel tank is becoming low.
Warning:
Out of range condition exists within the engine protection circuits.
Low Air:
Air tank pressure is low and the air system may not operate properly.
CAUTION:
Low Air Lamp only illuminates when a low air indication is present. Check the operation of
the Low Air Lamp when air tank is drained.
Check Trans:
Alerts of problems related to the Allison Transmission.
Stop Engine:
Alerts of severe out of range condition within the engine protection circuits. Pull over and shut the engine off
to avoid severe engine damage.
Gauges
080382b
1
2
3
4
5
6
8
7
