EnDaL smart PC SOFTWARE – MONI LOG® ANALYZER
- 21 -
4 . 2 . 2 F i l e a r e a
Data that are read out from a device can be saved as file. A click on the button
“Save file” opens the corresponding dialogue. A click on the button with the Excel symbol exports
the read-out files into an Excel file.
Figure 5: File area
Likewise, saved data can be fed again into the PC programme. The button “Load file” opens the
corresponding dialogue for the selection of the desired file.
4 . 2 . 3 M e s s a g e w i n d o w ( L o g )
The message window, which can be found as a programme tab “Log”, renders possible an
overview on the actions performed by means of the programme or the status changes of the
device during the established USB connection. Error messages and notes, e.g. for executing
configuration commands, connection establishment to devices, saving of data etc. are listed here.
Figure 6: Log-window
