EnDaL smart DEVICE DESCRIPTION OF MONI LOG® ENDAL SMART
- 17 -
3.5 MOUNT I N G I N F O R M A T I O N
The device can be attached by means of 3 fastening screws (see Figure 2) on the transported
goods, according to the marked mounting holes. Optionally, the device can also be mounted on
magnetic surfaces with the aid of magnetic bases.
For the mounting of the GPS antenna of the EnDaL it must be taken into account that
a clear view from the mounting location to the sky considerably improves the GPS reception
conditions. An enclosure or covering of the GPS antenna may considerably deteriorate the GPS
reception or even completely prevent it. A poor GPS reception may lead to an increased current
consumption and thus to a shortened device runtime.
Figure 2: Dimensions and mounting information of the EnDaL smart
