PC SOFTWARE – MONI LOG® ANALYZER EnDaL smart
- 28 -
Shock event thresholds:
Release threshold: acceleration value, above which the scanning is activated
Recording threshold shock magnitude: minimal amplitude of the acceleration
(storage criterion)
Recording threshold shock strength: minimal „area below the curve“ (storage criterion)
Recording threshold shock duration: minimal duration of the event (storage criterion)
Shock alarm threshold: acceleration value, above which an alarm event is created
Memory criterion: The shock event must reach at least the stated values to
befit for memory. This serves to hide the insignificantly
small shock events and in this way not to load excessively
memory and transmission path (Bluetooth & E-Mail).
Filled circle • : event active
Non-filled circle º : event not active
Event/alarm thresholds:
Temperature upper/lower: Upon exceedance/falling below, an event is created
Humidity upper/lower: Upon exceedance/falling below, an event is created
Inclination/inclination curve: If the device tilts from its zero position by the stated angle
(e.g. 30°), an event is created.
Inclination curves record the course of the tilting over a
period of some seconds.
Pressure upper/lower: Upon exceedance/falling below of the values, an event is
created
Notes on inclination events:
As the inclination is naturally superimposed with other movements and put under
general scatterings, the minimum threshold is limited to an angle of 5°. The scanning
is carried out with 12 Hz during a timeframe of 3 seconds; i.e., a faster tilting cannot
be detected under certain circumstances.
