- 73 -
User’s Manual
224-790-00K
May 2018
Programmable Limit Alarm Trips
SPA
2
SECTION 5
Figure 5.8. SPA
2
HLPRG Trimming Hook-Up Diagram For PC Configuration
VOLTAGE
SOURCE
_
+
Universal
Power
Supply
GND
AC/DC
AC/DC
2-WIRE
TRANSMITTER
_
+
.
CURRENT
SOURCE
_
+
.
+
- MULTIMETER
OR
DCS
TO SERIAL
(COM) PORT
OF PC
To USB
(COM)
Port of PC
PC
CURRENT OUTPUT SOURCE
+
-
+
-
EXTERNAL
POWER
SUPPLY
+
-
CURRENT OUTPUT SINK
MULTIMETER
OR
DCS
MULTIMETER
OR
DCS
+
-
MULTIMETER
OR
DCS
VOLTAGE OUTPUT
HOOK-UPS FOR OUTPUT TRIMMING
