Adjust angle
of wood chip
projection
Getting Started • Preparation
Figure 2.3
Electrical connection
Chain connection
Ball or pintle
hitch connection
Wheel chocks
Chipper should sit on
a level surface with the
machine parallel to the ground
NOTE: Some machines have a
height adjustor. See Features
and Functions section to adjust
the height of the discharge
chute using the height
adjustor
Infeed chute
and tray is clear
of debris
Electric brake
actuator cable
Break-away
switch
76347-281 • 12-08 2.5
