Morbark BEEVER M15R - After Engine Warm-Up

Engage clutch
Disengage clutch
Hydraulic Valve
will move into the
neutral position
when released.
Forward
pulls material into
the feed wheels
Stop
stops movement
of the feed wheels
Stop
stops movement
of the feed wheels
Reverse
pushes material out of
the feed wheels
The Chipping Cycle • Start-up
Figure 2.6
Safety
control bar
Clutch
Figure 2.5
Neutral
76347-281 • 12-08 2.7
After Engine warm-up:
1. Go to full throttle. Keep it at this speed during the chipping process.
2. Begin loading the brush. (see next page.)
