Morbark BEEVER M15R - Discharge Chute

3.26 76347-281 • 12-08
Discharge Chute
Figure 3.13
Discharge chute will rotate a complete 360º
Transition base
Discharge chute
Adjustable deflect
Manual swivel handle
Chain
Discharge
locking pin
Deflect handle
adjusts to four
angles
Height
adjustment
bolts and
holes
Features and Function • Components • Discharge Chute
