Morbark BEEVER M15R - PTO Chain, Belt, and Guards

3.56 76347-281 • 12-08
Feed wheel
chain guard
Feed wheel
chain
Hydraulic motor
Top feed wheel
Bottom sprocket
Top sprocket
Chipper drum
belt guard
Bottom sheave
PTO Chain, Belt, and Guards
Figure 3.35
Washers and
bolts
Chipper drum drive belt
Chipper drum
Top Feed Wheel Chain and Guard
Chipper Drum Belt and Guard
Figure 3.36
Top sheave
Features and Function • Components • PTO Chain, Belt, and Guards
