Morbark BEEVER M15R - Hydraulic Oil and Fuel Tanks

,
®
Hydraulic oil
filler cap
Hydraulic oil
vent cap
Fuel
filler cap
Hydraulic oil filter
Sight gauge
Sight gauge
Inspection cover
Valve
closed
Valve open
Fuel tank
Hydraulic oil tank
shut-off valve,
located below the
hydraulic tank
shut-off valve,
located top of
fuel tank
3.32 76347-281 • 12-08
Figure 3.15
*Feature varies depending on the model you have ordered, see the options tabs for details on your model.
Hydraulic Oil and Fuel Tank
Features and Function • Components • Hydraulic Oil and Fuel Tank
