Morbark BEEVER M15R - M15 R Left View

,
M15R Left View
Figure 3.2
3 4
5
8
7
Hitch and
chains
Fuel shut-off valve
Drum lock pin
Axle
bk
Bottom feed wheel
hydraulic motor
Radiator screen
Manual holder
Jack
bl
Fuel/Hydraulic
oil gauges and
filler cap
bm
6
Hydraulic
oil filter
Muffler
Adjustable
deflect
Deflect
handle
1
Rim and tire
Tool box
bn
2
Discharge
chute
bq bp
Telescoping
Tongue
bo
Flag holder
bt
ck
9
Top feed wheel
chain guard
br
bs
Hydraulic oil
shut-off valve
(bottom of the tank)
Features and Function • The Basics
3.4 76347-281 • 12-08
