Morbark BEEVER M18R - The Basics; Right View

3.2 76347-282 • 12- 08
Right View
9
3
2
Valve bank
Auto reverse
valve
bk
1
Safety control
bar
Engine drive belt guard
Figure 3.1
bl
Engine control panel
bn
Battery box
6
Hood locking pin
7
Manual swivel
discharge crank
bo
bp
Air filter housing
Clutch and
clutch handle
5
Yoke
4
Top feed wheel
8
Discharge locking pin
br
Safety cables
bs
Infeed
bt
bm
End view
Engine
Hydraulic yoke
cylinder
The Basics
bq
Yoke locking
pin
Bottom feed wheel
ck
Down pressure valve
Features and Function • The Basics • Rght View
