3.15
76347-282 • 12- 08
*Feature varies depending on the model you have ordered, see options tabs for details on your model.
Feed Wheel Chain Drive
Function
The feed wheel chain provides power to the top feed wheel. The chain
drive consists of the chain, two sprockets, two bushings, hydraulic motor,
and the chain guard.
Use
The feed wheel chain drive is housed inside the chain guard. Never
remove the chain guard unless you are changing, servicing, or cleaning
the components inside the guard. To remove the chain guard, loosen and
remove the bolts and washers on the sides of the guard. Lift the guard
off the machine. Always replace the belt guard and secure with the bolts
and washers after the work is completed.
To get top performance from the chain drive, it is important that the
chain has the proper tension. When adjusting the tension, you need to
increase the distance between the two sprockets by manually pulling on
the hydraulic motor.
Maintenance
Inspect sprockets for wear or damage when replacing the chain.
Moving chains will cause serious injury or death. Do not
operate without the guards in place. Do not attempt to
touch, check, clean, or adjust the chain during operation.
Safety
Features and Function • Components • Feed Wheel Drive
DANGER
To Next Page
