Function
The hydraulic valve bank controls operate the machine. They control the
yoke and aide in machine maintenance. The auto reverse valve stops the
feed wheel when low rpm’s are detected from the motor. It allows for
smooth shifts in direction (forward or reverse) of the feed wheels.
The chipper comes with several options, depending on what type of
options you have will dictate how many hydraulic handles your chipper is
equipped with. Check the Table of Contents for the options on your
chipper.
Use
Operating the machine is managed by moving the hydraulic handles. The
handles are located on the valve bank. All handles, except the Safety
Control Bar, have a spring mechanism that will return the handle to the
Neutral position when not in use.
Maintenance
• Check fittings and hoses for leaks
• Check coils for tightness
• Check for wear on wiring
WARNING
Relieve stored hydraulic pressure before
performing service to the hydraulic system.
Components could be hot to the touch.
Safety
Valve Banks
Features and Function • Components • Valve Banks
