Morbark BEEVER M18R - Discharge Chute Options

3.20 76347-282 • 12- 08
4
Discharge Chute Options
3
Height Adjustor
2
Bottom Clean-out
1 Side Clean-out
4 Hydraulic Swivel
3
To release the
toggle clamp and
open the front
panel, move the
handle down
To operate the
Hydraulic Swivel, see
decal next to the valve
handle for operating
instructions
Bottom
clean-out cover
To adjust the
height, crank the
turnbuckle
Unscrew the bolts and
remove the cover.
1
2
Discharge chute will rotate a complete
360º
Side clean-
out cover
Figure 3.9
Features and Function • Components • Discharge Chute Options
