3.12 76347-282 • 12-08
Figure 3.6
Feed Wheels and Chipper Drum
1
2
Bottom feed wheel
Chipper housing
Anvil
3
4
Chipper drum
5
Top feed wheel
Knife pocket
Discharge chute
Features and Function • Components • Feed Wheels and Chipper Drum
