Morbark BEEVER M18R - Hydraulic Oil and Fuel Tank

3.24 76347-282 • 12- 08
Figure 3.10
Hydraulic oil
filler cap
Hydraulic oil
sight gauge
Hydraulic oil
vent cap
Fuel shut-off valve
Fuel filler cap
Fuel sight gauge
Hydraulic oil filter
located on the back
side of the hydraulic
tank
Fuel tank
Hydraulic oil tank
Hydraulic Oil and Fuel Tank
Inspection cover
Features and Function • Components • Hydraulic Oil and Fuel Tank
