1. See OEM manual for maintenance intervals
2. Only grease zerts above aluminum grease seals.
3. Use the same grease that is in the bearing.
4.4 76347-282 • 12- 08
Lubricating the machine is vital to its operation. There are 57 points of
lubrication on the machine.
Lubricate the grease points as outlined on the schedule below.
Lubrication
General Maintenance • Lubrication
Key:
X = 1 shot of grease (Use only EP rated grease)
Table 4.2 • Routine Lubrication Schedule
Note: The following maintenance intervals apply for normal operating
conditions only. Intervals are hours of operation based on 8 hours per
day, 5 days per week. If your operating conditions are difficult, adjust the
specified intervals.
Description
Number of
locations
Start
up
8
hours
40
hours
Wheel axle (1) 2
Feed wheel bearings 2 X
Clutch (1) 4
Yoke cylinder pins 2 X
Yoke pivot pins 2 X
Discharge chute swivel & crank
handle
3 X
Drum bearing grease slingers
(2,3)
4 X
Jack hand crank 4 X
Control Bar 2 X X
Battery Box 2 X
Front Stabilizers (Optional) 4 X
Rear Stabilizers (Optional) 4 X
Winch (Optional) 4 X
