3.9
76347-282 • 12- 08
Infeed
Options
Running the engine while a person is performing
maintenance will result in serious injury, dismemberment,
or mutilation. Always follow proper lockout procedures
before performing maintenance. In an emergency, press
the emergency stop button, if equipped, or immediately
shift the safety control bar into the neutral position.
DANGER
Function
There are five options available for the infeed they are; rubber infeed
curtain with pulley safety cables, spring assist folding tray, emergency
stop button, folding tray, and European model. Your chipper may have a
combination of these options.
1. Rubber Infeed Curtain with Pulley Safety Cables: The
rubber infeed curtain keeps debris from flying back towards the
operator. When your chipper is equipped with a rubber infeed
curtain you must use the pulley safety cable system. This system
routes the safety cables to the outside of the rubber guard.
2. Spring Assist Folding Tray: Assists in raising or lowering the
folding tray.
3. Emergency Stop Button: Allows the operator to shut down the
engine in an emergency situation only!
4. Hydraulic Folding Tray: Opens and closes the folding tray
through hydraulic power.
5. Folding Tray: Shortens length of infeed for transport. Keeps
debris from flying out and harming bystanders and other vehicles
when towing the chipper.
Safety
Use
Rubber infeed curtain and Pulley Safety Cables: Pull the safety
cables straight down to reverse the feed wheels.
Spring Assist Folding Tray: The spring assist mechanism helps raise
and lower the tray with ease. Lock the tray using the infeed tray
locking pins.
Emergency Stop Button: Push the red emergency stop button in
until the engine stops. Pull the stop button back out after the engine
has completely shut down. If the button is not pulled out the engine
will not restart. Important!: The feed wheels and chipper will
continue to turn after engine has been shut off.
Hydraulic Folding Tray: To change the direction of the infeed tray
(folded up or down), move the manifold handle on the valve bank.
Lock the tray using the infeed tray locking pins.
Folding Tray: To unlock the folding tray, pull the locking pins
towards the center of the tray, and fold the tray down. Lift the tray up
and lock into place when not in use.
Maintenance
• Keep the infeed clear of any debris (stones, glass, metal, etc.) that
may damage the machine
• Clean the infeed only when the ignition key is out, engine control
panel is locked, and the machine is stable
• Clear the infeed of all debris before towing
Features and Function • Components • Infeed Options
