ENGLISH
1.3.1 TECHNICAL SPECIFICATIONS (FIG.2)
3-point hitch..........................class I - II I - II I - II I - II
Number of disks......................n°4567
Number of tines for disk.........n°2222
Disk rotation speed
for PTO=540........................... rpm 3080 3080 3080 3080
Minimum power rating........kW-HP 26 - 35 30 - 40 34 - 46 38 - 52
(A)-Working width..............mm-inch 1650 - 64,96 2100 - 80,70 2400 - 94,48 2800 - 110,23
(D)-Transporting width.......mm-inch 1350 - 53,14 1350 - 53,14 1350 - 53,14 1350 - 53,14
(B)-Machine width..............mm-inch 3490 - 137,40 3890 - 153,15 4290 - 168,89 4690 - 184,64
(C)-Machine lenght.............mm-inch 1250 - 49,21 1250 - 49,21 1250 - 49,21 1250 - 49,21
(E)-Machine height.............mm-inch 1390 - 54,72 1390 - 54,72 1390 - 54,72 1390 - 54,72
Total weight (*)........................ kg 465 505 545 585
(*) excluding cardan shaft.
1.3.2 TRACTOR REQUIREMENTS
PTO................................................................... rpm 540
Minimum power rating...................................kW-HP da 26-35 a 38-52 according to model
Maximum pressure hydraulic system............. bar 160
Single-acting spool valve..................................n° 1
1.3.3 PACKAGING FOR SHIPMENT
The weights of the rectangular shaped packages standard / on pallet and the dimensions are listed below:
Package (*)Weight Length Width Height
(kg) (mm)/(inch) (mm)/(inch) (mm)/(inch)
n°1 mower with 4 disks 515 / 525 2500 / 98.42 740 / 29.13 740 / 29.13
n°1 mower with 5 disks 550 / 560 2500 / 98.42 740 / 29.13 740 / 29.13
n°1 mower with 6 disks 595 / 605 2650 / 104.3 740 / 29.13 740 / 29.13
n°1 mower with 7 disks 650 / 660 3050 / 120.0 740 / 29.13 740 / 29.13
(*) overall weight of the pack including the cardan shaft.
1.4 NOISE LEVEL
The noise level issued by the machine is checked for all
models.
In view of the measurements taken in the various positions
examined, the operator must use individual protective
equipment to safeguard the hearing.
WARNING
It is obligatory to use individual protective
equipment to safeguard the hearing.
However, there are other factors that can influence the level
of sound exposure, such as the characteristics of the place
of work, the length of exposure and the presence of other
sources of noise.
The information about the level of noise issued by the
machine will help the user or employer to evaluate the rela-
tive risks and dangers.
Noise level: dB(A) 87
1.5 PACKING AND TRANSPORT FOR
DELIVERY
To facilitate shipment and reduce transport costs, the
machines are supplied by the Manufacturer PARTIALLY
DEMOUNTED in packages crates.
If the machine must be transported over a long distance, it
may be loaded on a truck or railway freight wagon.
WARNING
Use a crane or lift trucks of an adequate carrying
capacity to lift and handle the packed machine,
in compliance with the common safety norms.
Consult chapter 1.3.3 for the weights and dimensions table.
