ELI 250/210 _________________________________________________________________________
4-12
Flip the unit over and remove the 4 screws, item 14, holding the writer to the bottom chassis.
CAUTION
Due to the weight of the battery, the bottom chassis of the unit may tilt off the writer while
the unit is upside down. Make sure that the bottom chassis is supported while performing
this procedure.
Lift the bottom chassis straight off of the writer assembly.
Re-assemble in reverse order.
