Mortara ELI 210 - Parts List

ELI 250/210__________________________________________________________________________
5-6
Parts List
Item Number Part Number Description
1 26025-039-XX Motherboard PCB Assembly
2 26025-039-XX Motherboard PCB Assembly
3 26025-040-51 Keyboard PCB Assembly ELI 250
4 26025-051-50 Keyboard PCB Assembly ELI 210
5 26025-043-XX 10k+ Front End Amplifier PCB Assembly
6 4021-001 Fuse Type T, 250V, 1A, 5 x 20MM SLO
7 4021-006 Fuse, 5 AMP, TYPE T, SLO BLO 250V
8 4110-006 Fuse Holder, 5 x 20 Panel Snap-In mount
9 4160-026-51 Elastomeric Keypad ELI 250
10 4160-027-50 Elastomeric Keypad ELI 210
11 4800-006 Rechargeable Battery, 12V, 2.2Ah
12 5400-014 LCD Panel 320 x 240, 3.9" mono
13 5450-004 Thermal Printhead, 216mm 8.50"
14 6545-006-01 Stepper motor PM 35mm 1-2PH 48 STEP/R
15 6570-842-02 Platen / Shaft 8.421 x .551
16 690-1225 Lithium Battery, 3V, 38 mAH SM
17 8342-001-XX Upper Housing
18 8342-002-XX Lower Housing
19 8342-003-XX Paper Tray Cover
20 8342-004-50 Gear Box Assembly
21 8342-005-XX Paper Tray
22 8342-015-50 Keyboard Bezel ELI 250
23 8343-001-50 Keyboard Bezel ELI 210
24 8342-016-XX Bulkhead Back Panel
25 8342-021-50 LCD Bezel ELI 250
26 8343-002-50 LCD Bezel ELI 210
27 9050-055-01 Nameplate Label ELI 250
28 9042-030-01 Nameplate Label ELI 210
29 9205-062-50 Shipping Carton Assembly
30 9042-030-XX Label User Instructions
31 9042-035-01 Bulkhead Label Blank
32 25018-035-50 Cable assembly 14 conductor
33 25020-053-50 Speaker assembly
34 25018-036-50 Keyboard to Motherboard cable
35 25020-059-51 Cable assembly battery to PCB
36 6320-003 Adhesive rubber foot
37 9042-033-01 AC/Battery charged label
38 8342-021-XX LCD Bezel
