ELI 250/210__________________________________________________________________________
5-4
Patient Input
Connector: Pin #: Name: Description:
1 V2 Patient Lead
2 V3 Patient Lead
3 V4 Patient Lead
4 V5 Patient Lead
5 V6 Patient Lead
6 SHIELD Isolated Front-End Ground
7 Reserved
8 Reserved
9 RA Patient Lead
10 LA Patient Lead
11 LL Patient Lead
12 V1 Patient Lead
13 Reserved
14 RL Patient Lead
15 Reserved
