12 User Guide - v11
PoE HD Interceptor Camera
The PoE HD Interceptor Camera variant is a ruggedized aluminum encased PTZ HD camera.
This camera should be powered by an Ultra PoE (802.3bt) source.
247mm / 9.72in 399mm / 15.71in Pan Sweep
410.5mm / 16.16in
View on Side FaceView on Front Face
View on Bottom Face
350.5mm / 13.80in
11.0mm /
0.43in
4 x Diameter
9.00mm / 0.35in
102mm / 4.06in PCD
Diameter
125mm / 4.92in
Mounting Base
Diameter
248mm /
9.76in
Tilt Sweep
Figure 6: PoE HD Interceptor Camera variant
Dimensions
• 247mm / 9.7 in (w) x 350.5mm / 13.80 in (h)
• Pan sweep:
• 399mm / 15.71 in (w) x 410.5mm / 16.16 in (h)
Weight
• 7.49 Kg (16.5 lbs) (excluding packaging)
2 Hardware Description HD Interceptor Camera - Specialized Range
