Mounts
All variants of the HD Interceptor Camera use the Hinge mount.
Hinged mount
The hinged mount provides easy access and installation options. This option allows for a
quick installation.
102mm / 4.02in
Figure 7: Hinged mount
Connections
Hinged mount connections
All connections are on the base of the camera.
CON 4
CON 5
30VDC
CON 6
CON 7
CON 8
Figure 8: All variants (except PoE)
