8 User Guide - v11
Variants
The HD Interceptor Camera is available in the following variants:
• HD Interceptor Camera
• HD Interceptor Camera with IR and white light illumination (IR250W)
• HD Interceptor Camera with powerful IR illumination (IR275)
• HD Interceptor Camera with powerful spot IR illumination (IR550S)
• PoE HD Interceptor Camera
Ensure that you read the instructions within this document relating to the camera variant you
have been shipped.
The camera is IP68 rated. There are no user serviceable parts. Servicing should only be
performed by qualified personnel. If a camera malfunctions contact IndigoVision Technical
Support for assistance at technical.support@indigovision.com.
HD Interceptor Camera
The HD Interceptor Camera variant is a ruggedized aluminum encased PTZ HD camera.
247mm / 9.72in 399mm / 15.71in Pan Sweep
410.5mm / 16.16in
View on Side FaceView on Front Face
View on Bottom Face
350.5mm / 13.80in
11.0mm /
0.43in
4 x Diameter
9.00mm / 0.35in
102mm / 4.06in PCD
Diameter
125mm / 4.92in
Mounting Base
Diameter
248mm /
9.76in
Tilt Sweep
Figure 2: HD Interceptor Camera variant
Dimensions
• 247mm / 9.7 in (w) x 350.5mm / 13.80 in (h)
• Pan sweep:
• 399mm / 15.71 in (w) x 410.5mm / 16.16 in (h)
2 Hardware Description HD Interceptor Camera - Specialized Range
