User Guide - v11 9
Weight
• 7.49 Kg (16.5 lbs) (excluding packaging)
HD Interceptor Camera with IR and white light (IR250W)
The HD Interceptor Camera with IR and white light illumination is a ruggedized aluminum
encased PTZ HD camera. It includes a white light source for better night- time facial
recognition.
250mm / 9.84in
420mm / 16.54in Pan Sweep
422mm / 16.61in
View on Side FaceView on Front Face
View on Bottom Face
380mm / 14.96in
11.0mm /
0.43in
4 x Diameter 9mm
102mm / 4.02in PCD
Diameter
125mm / 4.92in
Mounting Base
Diameter
270mm /
10.63in
Tilt Sweep
Figure 3: HD Interceptor Camera variant with IR and white light illumination
Dimensions
• 250mm / 9.84 in (w) x 380mm / 14.96 in (h)
• Pan sweep:
• 420mm / 16.54 in (w) x 422mm / 16.61 in (h)
Weight
• 8.25 Kg (18 lbs)
HD Interceptor Camera - Specialized Range 2 Hardware Description
