Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A) 8-39
C2483M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2504M6 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C2506M6 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C2518M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C2520M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2527M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2528M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2531M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2532M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2534M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2535M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2536M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2538M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2539M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2540M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C2541M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2542M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2543M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2544M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2545M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2546M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2548M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2549M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2550M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2551M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2552M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2553M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2554M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2555M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C2601M13 2113944C45 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C2602M13 2113944C41 CAP,CHIP,68PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C2603M13 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2604M13 2113944C45 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX
C2605M13 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2606M13 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C2607M13 2113944C19 CAP,CHIP,3.6PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
C2608M13 2113944C21 CAP,CHIP,4.3PF,.25PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMA
C2609M13 2113946K02 CAP,CHIP,.1UF,+80%,-
20%,16V-DC,0402,Y5V,-
30DEG CMIN,85DEG CMAX
C2806 NOT
PLACED
CAP,FXD,.1PF,.03PF+/-,25V-
DC,C0G,-55DEG
CMIN,125DEG CMAX,PB-F
C3100M22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C3101M22 2115153H21 CAP,FXD,5.6PF,.1PF+/-,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
C3102M22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C3103M22 NOT
PLACED
CAP,CHIP,2.7PF,.25PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMA
Ref. Des. Part Number Description
C3104M22 NOT
PLACED
CAP,FXD,10PF,.1PF+/-
,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
C3105M22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C3106M22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C3107M22 2115153H23 CAP,CER CHIP,6.8PF,.1PF+/
-,+.1%,-.1%,50V-
DC,0402,C0G,CAP, CERA
C3108M22 NOT
PLACED
CAP,CHIP,2.7PF,.25PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMA
C3109M22 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C3110M22 2115153H16 CAP,CERAMIC
CHIP,3.6PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
C3111M22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C3112M22 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C3113M22 2113944M15 CAP,FXD,7.5PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3114M22 NOT
PLACED
CAP,FXD,10PF,.1PF+/-
,+1%,-1%,50V-
DC,0402,C0G,CAP,
CERAMIC, COG
C3115M22 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3116M22 2113944M14 CAP,FXD,6.8PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
