Motorola APX 3000

Troubleshooting Tables: List of Board and IC Signals 7-13
Table 7-8. Primary IC Reference Designator
Primary IC
Reference
Designator
Component Location
OMAP 1710 U6302 MAIN BOARD (top-side)
DDR memory U6301 MAIN BOARD (top-side)
FLASH IC U6304 MAIN BOARD (top-side)
CPLD U6101 MAIN BOARD (top-side)
Audio Codec U6405 MAIN BOARD (bottom-side)
MACE U2510 MAIN BOARD (bottom-side)
MAKO U6501 MAIN BOARD (bottom-side)
Top Lighting Controller U2205 MAIN BOARD (top-side)
BLUETOOTH & GPS Combination IC U1301 MAIN BOARD (bottom-side)
BlueTooth AVR processor U2415 MAIN BOARD (top-side)
SDRAM U2413 MAIN BOARD (top-side)
Accelerometer U2416 MAIN BOARD (bottom-side)
Battery contact springs M101 MAIN BOARD (bottom-side)
VCO (UHF1) Q3123 MAIN BOARD (bottom-side)
VCO (UHF1) Q3156 MAIN BOARD (bottom-side)
VCO (7800) Q3038 MAIN BOARD (bottom-side)
VCO (7800) Q3039 MAIN BOARD (bottom-side)
VCO (7800) Q3062 MAIN BOARD (bottom-side)
PA Final stage device Q1001 MAIN BOARD (bottom-side)
Mixer U507 MAIN BOARD (top-side)
Trident U702 MAIN BOARD (top-side)
Abacus III U601 MAIN BOARD (bottom-side)
