7-12 Troubleshooting Tables: List of Board and IC Signals
Note:
* PU = Pull Up
* PD = Pull Down
omap_tdo JTAG Data out from
Controller
AA19 Output 0 Output None
tdi JTAD Data in from
JTAG box to
Controller
Y19
Input Input Pull-
down
nemu0 "Emulation pin 0, not
used, pulled high on
PCB
"V16 I/O Input Pullup
nemu1 "Emulation pin 1, not
used, pulled high on
PCB
"W17
I/O Input Pullup
Table 7-7. Overall GPIO pin functions (Continued)
Signal Name Description
Pin or
Ball #
Active State
SW Initialized HW Reset
Direction
*
PU State Direction
*
PU or
PD
