Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A) 8-41
C6108M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6109M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C610M19 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6110M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6111M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6112M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6113M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6114M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6115M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C611M19 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C612M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C613M19 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C614M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C6155M6 NOT
PLACED
CAP,FXD,13PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,PB
Ref. Des. Part Number Description
C6156M6 NOT
PLACED
CAP,FXD,13PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C615M19 2113944A42 CAP,CHIP,150PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C616M19 2113945A11 CAP,CHIP,2200PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C617M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C618M19 2113944A31 CAP,CHIP,33PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C619M19 2113944A35 CAP,CHIP,62PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX,P
C6201M6 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C6202M6 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C6203M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C620M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C621M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C622M19 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C623M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
Ref. Des. Part Number Description
C624M19 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C625M19 2115153H39 CAP,FXD,18PF,50V-
DC,0402,C0G
C626M19 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C627M19 2113945A09 CAP,CHIP,1000PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C628M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C629M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6301M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6302M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6303M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6304M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6305M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6306M6 2113946S35 CAP,CHIP,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6308M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6309M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C630M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
C6310M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6311M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C631M19 2115153H32 CAP,FXD,8PF,.1PF+/-,+.1%,-
.1%,50V-DC,0402,C0G,CAP,
CERAMIC, CO
C632M19 2113944A40 CAP,CHIP,100PF,+5%,-
5%,50V-DC,0402,C0G,-
55DEG CMIN,125DEG
CMAX
C633M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C634M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C635M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C636M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C637M19 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C638M19 2113945A12 CAP,CHIP,3300PF,+10%,-
10%,50V-DC,0402,X7R,-
55DEG CMIN,125DEG CM
C639M19 2113945B02 CAP,CHIP,.01UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C6402M6 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6403M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C6404M6 2113946B04 CAP,CHIP,.1UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
Ref. Des. Part Number Description
