Motorola APX 3000

8-56 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A)
R6617M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6618M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6619M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6621M6 0613952Q89 RES,MF,4700,5,.0625,SM,04
02,200,PB-FREE
R6622M6 0613952Q35 RES,MF,27OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R6623M6 0613952Q35 RES,MF,27OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R6624M6 0613952Q35 RES,MF,27OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R6625M6 0613952Q35 RES,MF,27OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R6626M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6701M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6702M6 0613952R17 RES,MF,47000,5,.0625,SM,0
402,200,PB-FREE
R6703M6 0613952R17 RES,MF,47000,5,.0625,SM,0
402,200,PB-FREE
R6704M6 0613952R17 RES,MF,47000,5,.0625,SM,0
402,200,PB-FREE
R6705M6 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
R6706M6 0613952Q73 RES,MF,1KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R698M19 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
R699M19 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
Ref. Des. Part Number Description
R701M7 0613952Q64 RES,MF,430OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R702M7 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
R703M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R704M7 0613952Q25 RES,MF,10,5,.0625,SM,0402
,200,PB-FREE
R705M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R706M7 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
R707M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R708M7 0613952Q45 RES,MF,68OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R709M7 NOT
PLACED
RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
R710M7 NOT
PLACED
RES,MF,33OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R711M7 NOT
PLACED
RES,MF,33OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R721M7 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R722M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R723M7 0613952Q79 RES,MF,1800,5,.0625,SM,04
02,200,PB-FREE
R728M7 0613952Q69 RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R729M7 0613952R09 RES,MF,22000,5,.0625,SM,0
402,200,PB-FREE
R730M7 0613952Q79 RES,MF,1800,5,.0625,SM,04
02,200,PB-FREE
Ref. Des. Part Number Description
R731M7 0613952Q86 RES,MF,3.6KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R736M7 0613952R66 RES,MF,0OHM,5%,.0625W,S
M,0402,PB-FREE
R741M7 0613952R09 RES,MF,22000,5,.0625,SM,0
402,200,PB-FREE
R742M7 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R743M7 0613952R17 RES,MF,47000,5,.0625,SM,0
402,200,PB-FREE
R744M7 0613952Q91 RES,MF,5600,5,.0625,SM,04
02,200,PB-FREE
R745M7 0613952R09 RES,MF,22000,5,.0625,SM,0
402,200,PB-FREE
R746M7 0613952Q36 RES,MF,30OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R747M7 0613952Q39 RES,MF,39OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R748M7 0613952Q47 RES,MF,82OHM,5%,.0625W,
SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R751M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R754M7 NOT
PLACED
RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R757M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R761M7 0613952Q23 RES,MF,8.2OHM,5%,.0625W
,SM,0402,200PPM/CEL,PB-
FREE
R762M7 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R763M7 0613952R19 RES,MF,56KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R766M7 0613952Q92 RES,MF,6.2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R769M7 0613952Q31 RES,MF,18OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R771M7 0613952Q49 RES,MF,100,5,.0625,SM,040
2,200,PB-FREE
R776M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R785M7 0613952Q49 RES,MF,100,5,.0625,SM,040
2,200,PB-FREE
R799M7 0613952Q49 RES,MF,100,5,.0625,SM,040
2,200,PB-FREE
R809M7 0613952Q46 RES,MF,75OHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R822M7 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R823M7 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
SH1 26012246001 SHLD,STL,SN PLT,SHIELD,
IF, APX CVT
SH10 26012250001 SHLD,STL,SN PLT,SHIELD,
ANTSWI, APX CVT
SH11 26012258001 SHLD,STL,SN PLT,SHIELD,
ABACUS, APX CVT
SH12 26012251001 SHLD,STL,SN PLT,SHIELD,
PAOP, APX CVT
SH13 26012260001 SHLD,STL,SN PLT,SHIELD,
DRIVER/PA, APX CVT
SH14 26012252001 SHLD,STL,SN PLT,SHIELD,
ALC/DC, APX CVT
SH15 26012261001 SHLD,STL,SN PLT,SHIELD,
VCO, APX CVT
SH16 26012254001 SHLD,STL,SN PLT,SHIELD,
CONTROLLER/AVR, APX
CVT
SH17 26012262001 SHLD,STL,SN PLT,SHIELD,
MACE/MAKO, APX CVT
Ref. Des. Part Number Description
