Motorola APX 3000

8-58 Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF1 (84012513001_A)
U2412M3 5114007M45 IC,NOR,1PER PKG,SOT-
353,PB-FREE
U2413M3 51010274001 IC,SDRAM,128MB,8MEG X
16,7.5NS,VFBGA,3.3V,IC,SD
RAM,128MBIT,8M
U2414M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANSCEIVE
R W/VOLTAGE TRANSLATI
U2415M3 51009372001 IC,UCNTLR,IC UCNTLR
AT32UC3A0512
U2416M3 51009669001 IC,SENSOR,SM,IC,
ACCELEROMETER,
MOTION SENSOR
U2473M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANSCEIVE
R W/VOLTAGE TRANSLATI
U2478M3 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANSCEIVE
R W/VOLTAGE TRANSLATI
U2510M6 5185912Y03 IC,MICROP,BGA,CRYPTOG
RAPHIC
PROCESSOR,IC,CRYPTOG
RAPHIC P
U2525M6 5171339H01 IC,MC78LC18,MICROPOWE
R V REGLTR
U2526M6 5171988H01 IC,COMPTR,CMOS
COMPTR
U2601M13 5103535B53 IC,INVTR,DL,NC7WZ04L6X,
2PER PKG,SC70
U2602M13 5185941F45 ATTEN,VAR,14.4DBMIN,15.6
DBMAX,0-2000
MHZFREQ,50OHM,PCMT,S
OT-25
U3001M22 5171972L01 IC,SW,SP3T RF SW
U4001M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U4003M2 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,SM
,SC70-6,1PER PKG,BUS,PB
FREE
Ref. Des. Part Number Description
U4004M2 5116783H01 IC,ANLG
SW,SN74LVC2G66YZPR,SM
,2PER
PKG,0CHANNELS,BILATER
AL,DL
U507M21 5164015H81 IC,MXR,SM
U601M19 5102495J14 IC,IF,IF DIGITILIZING
SUBSYSTEM
IC,AD9864,QFN
U602M19 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,S
MT,6V,380W,80A,14MHZ,TR
U603M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U604M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U605M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANSCEIVE
R W/VOLTAGE TRANSLATI
U606M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANSCEIVE
R W/VOLTAGE TRANSLATI
U607M19 5186311J24 IC,BFR,1PER
PKG,NC7SZ125,ACTIVE
HIGH,BFR,3ST,SM,5.5
U6101M6 0180706J18 IC,PGM,PGM CPLD
U6102M6 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,SM
,SC70-6,1PER PKG,BUS,PB
FREE
U6103M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6104M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6105M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6201M6 5185941F26 IC,COMPTR,LMV7219,SM,S
OT-23/
5,IC,LM7219,COMPARATOR
,NOPB
U6301M6 51012031001 IC,SDRAM,32MB,16 MEG
X16,6.5NS,VFBGA,64MSRF
RSH,32MB DIE SHRIN
Ref. Des. Part Number Description
U6302M6 5102495J13 IC,MICROP,P1710ZZGE,BG
A,12MHZ,32BITS
U6304M6 0105955U25 ASSY,ASSY,ASSY,IC,BGA
SPEC PROG, FLSH MEM
U6402M6 5115453H01 IC,OP AMP,2PER PKG,RAIL
TO RAIL OUTPUT, 8 PIN
BGA
U6404M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6405M6 5188348V06 IC,AUDIO
CODEC,SM,AUDIO CODEC
U6408M6 5188521T01 IC,VREF,SM,SOT23,1PER
PKG,.5%,1.25 TO
13.75,PRCN BANDGAP
ADJUS
U6409M6 51009000001 IC,COMPTR,SC70,NANOPO
WER, 1.8V, SC70 COMPTR
U6501M6 5185143E77 IC,CUST,BGA,IC, MAKO
ASIC, CMOS PWR MGMT
U6502M6 4871987H01 XSTR,BIP GP
POWER,12V,1A,LOW FREQ
XSTR
U6503M6 5171674H01 IC,OP AMP,SO-8,OP AMP
U6504M6 5171682H01 IC,DC TO DC
CONVERTER,800MA BUCK
REGLTR
U6505M6 5189631P01 IC,0PER PKG,SYNC
STEP-DOWN CONV
U6506M6 5184790Y04 IC,LINEAR VOLTAGE
REGULATOR,400MA
U6507M6 5171682H01 IC,DC TO DC
CONVERTER,800MA BUCK
REGLTR
U6508M6 51009366001 IC,LNR V
REGLTR,LLP6,500MA LOW
DROPOUT CMOS LINEAR
REG
U6509M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6510M6 5114007A47 IC,OR,17SZ32,1PER
PKG,SOT-353,PB FREE
U6511M6 5171339H01 IC,MC78LC18,MICROPOWE
R V REGLTR
Ref. Des. Part Number Description
U6601M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U702M7 5164015H28 IC,CUST,MULTI
PROTOCOL/BAND
TRANSCVR
IC,SM,BGA,TRIDENT,
INTEG
U738M7 5171972L01 IC,SW,SP3T RF SW
U746M7 4805218N63 XSTR,GEN PURPOSE
SMALL SIG,SOT-
323,BROADBAND AND
XSTR
VR101M12 4813977M29 DIODE,ZEN,MBZ5250,SM,S
OT-23,ZEN,PB-FREE
VR1905M20 4815096H01 DIODE,VCTR,10V,1SV305G,
VCTR DIODE 1SV305
VR1906M20 4815096H01 DIODE,VCTR,10V,1SV305G,
VCTR DIODE 1SV305
VR1907M20 4815096H01 DIODE,VCTR,10V,1SV305G,
VCTR DIODE 1SV305
VR1908M20 4815096H01 DIODE,VCTR,10V,1SV305G,
VCTR DIODE 1SV305
VR200M12 4813977M29 DIODE,ZEN,MBZ5250,SM,S
OT-23,ZEN,PB-FREE
VR601M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/
SC-79,SOD-523/SC-79
VR602M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/
SC-79,SOD-523/SC-79
Y1304M3 48014600001 OSC,TCXO,26.0
Y2475M3 48009319001 OSC,VAR,SMD XTAL OSC
DS0211AR
Y6501M6 93012044001 OSC,XO,24.576MHZ,SM,XT
AL U SMD 5.0X3.2
24.576MHZ
Y6502M6 4809995L05 RESON,QRTZ,32.768KHZ,S
M,FUND,9PF LOAD CAP,-
40DEG C MIN,85DE
Y6601M6 4802582S85 RESON,QRTZ,12MHZ,10PP
M TOL,18PPM
STAB,SM,FUND,AT,10PF
LOAD CAP
Ref. Des. Part Number Description
