Motorola APX 3000

Schematics, Boards Overlays, and Parts Lists: Main Board Block: 700–800 MHz (84012501002) 8-107
R2115M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2116M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2117M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2118M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2120M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2197M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2198M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2199M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R21M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2201M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2204M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2206M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2207M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2235M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2244M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2245M2 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R2246M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R2254M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2255M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2256M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2257M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R22M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2301M13 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2302M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2303M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2304M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2306M13 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2356M2 0613952Q09 RES,MF,2.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2357M2 0613952Q09 RES,MF,2.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2358M2 0613952Q66 RES,MF,510OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2359M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2360M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2361M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R2362M2 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2363M2 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2364M2 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2401M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2404M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2405M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2406M3 NOTPLACED RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2407M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2408M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2412M3 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2414M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2416M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2418M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2419M3 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2433M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2434M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2435M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R2436M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2437M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2441M3 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2442M3 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2443M3 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2444M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2449M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2450M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2451M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2452M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2453M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2454M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2455M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2456M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2457M3 0613952R05 RES,MF,15KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
