8-148 Schematics, Boards Overlays, and Parts Lists: Main Board Block: VHF (84012512001_A)
VHF Transceiver (RF) Board Parts List –
84012512001_A
Ref. Des. Part Number Description
C101M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1103M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1104M11 NOTPLACED 64AM DUMMY PART
NUMBER
C1105M11 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1106M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1107M11 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1108M11 2113946B02 CAP CER CHP 0.047UF
10V 10,
C1110M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1111M11 21139 45Y02 CAP,F XD,. 1UF,+10 %,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1112M11 2113945B01 CAP CER CHP 6800PF 25V
10%
C1113M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1116M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1117M11 2113945A12 CAP CER CHP 3300PF 50V
10%
C1118M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1119M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1120M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1122M11 2113944M05 CAP,FXD,3PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C1123M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1124M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1125M11 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C1126M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1127M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1128M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1129M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1130M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1137M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1138M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1139M11 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C1140M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1141M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1142M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1156M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1157M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1158M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1159M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
Ref. Des. Part Number Description
C1160M11 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C1161M11 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C1162M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1163M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1164M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1165M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1166M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1167M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1168M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1169M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1170M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1171M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1172M11 2113944A27 CAP CER CHP 15.0PF 50V
5%
C1203M17 2113944M12 CAP,FXD,5.6PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1204M17 2113944M11 CAP,FXD,5.1PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1207M17 2113944M28 CAP,FXD,27PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
Ref. Des. Part Number Description
C1220M17 2113944M16 CAP,FXD,8.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1221M17 2113944M27 CAP,FXD,24PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1222M17 2113944C04 CAP CER CHP 330.0PF
50V 5%
C1226M17 2175662M26 CAPACITOR 4.3 ?0.1PF,
CERAMIC, 100V
C1227M17 2113944M17 CAP,FXD,9.1PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1301M3 21012119001 CAP,FXD,2.2UF,20%,6.3V-
DC,-55DEG CMIN,85DEG
CM,X5R,0402
C1302M3 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1303M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1304M3 2113944A07 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C1305M3 2113944A27 CAP CER CHP 15.0PF 50V
5%
C1306M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
C1307M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1308M3 2113945A09 CAP CER CHP 1000PF 50V
10%
C1309M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1310M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
C1311M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
