Schematics, Boards Overlays, and Parts Lists: Main Board Block: UHF2 (84012616001) 8-219
R2488M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2489M3 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2490M3 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2491M3 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2492M3 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2493M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2495M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2496M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2497M3 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2501M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2503M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2505M6 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2507M6 0613952R49 RES,MF,1MOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2508M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2509M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2511M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R2512M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2513M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2514M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2515M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2516M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2517M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2519M6 0613952H25 RES,MF,10OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2522M6 0613952R74 RES,MF,10MOHM,5%,.0625
W,SM,0402,400PPM/
CEL,PB-FREE
R2523M6 0613952R74 RES,MF,10MOHM,5%,.0625
W,SM,0402,400PPM/
CEL,PB-FREE
R2524M6 0613952R49 RES,MF,1MOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2529M6 0613952P30 RES,MF,200000,1,.0625,SM
,0402,200,PB-FREE
R2530M6 0613952P30 RES,MF,200000,1,.0625,SM
,0402,200,PB-FREE
R2560M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2601M13 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2602M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2603M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2604M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
Ref. Des. Part Number Description
R2605M13 0613952G67 RES,MF,0,1,.1,SM,0603,PB-
FREE
R2606M13 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2803 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2804 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2805 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2806 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2807 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2808 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2810 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2811 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2812 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2813 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2817 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3101M22 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R3103M22 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3105M22 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R3106M22 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3107M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3108M22 0613952Q38 RES,MF,36OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3109M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3114M22 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3118M22 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R3127M22 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R3146M22 0613952Q95 RES,MF,8.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3149M22 0613952Q95 RES,MF,8.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3158M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3159M22 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3160M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4005M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4006M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4007M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
