Connecting Your DCX Set-top to an A/V Receiver,
SDTV, and VCR/DVD Recorder
Note: Solid lines indicate optimum connections.
Note: Consult your A/V receiver manual for additional wiring options or constraints when
including a VCR/DVD Recorder in your configuration.
If degraded picture quality is observed while viewing copy-protected
limited view programs, do not connect through a VCR. Instead, connect
the set-top directly to the TV.
