Motorola FW200L User Manual

52 FM Radio
10.5 Channel list
1. Go to the FM Radio menu (see above) and press Options .
2. Scroll
d to Channel list and press Select .
3. The saved channels are listed (only the first 3 are visible), scroll
d to the
required channel and press
Select .
4. Scroll
u or d to either Play , Delete or Edit and press Select .
5. If
Play is selected, the radio will turn on.
6. If
Delete is selected, press Yes to delete or No to cancel.
7. If
Edit is selected you have can edit the channel name and frequency.
Options Actions
Edit The channel name is highlighted, press Options and Select
to edit the name, press
Clear to delete the current name
and then using the keypad enter the new name, press
Options and then Select . Scroll d to Frequency , press Clear
to delete the current channel and then using the keypad
enter the new channel (press
to enter a decimal
point). Press
Options and then Select to save.
8. Press
o to return to standby.
Note
The name of the radio channel will be displayed when the radio is on and the
screen is in standby mode.

Motorola FW200L Specifications

General

Phonebook capacity	1000 entries
Short Message Service (SMS)	Yes
Redial list capacity	20
Backlight color	Blue
Display diagonal	2.2 \
Display resolution	128 x 64 pixels
LED indicators	Power
Elderly phone	No
Mounting type	Desk
Product color	Black
Buttons quantity	22
Languages support	ARA, DEU, ENG, ESP, FRE, ITA, POR, RUS, TUR
Number of handsets included	1
Standby time	168 h
Input current	1 A
AC input voltage	5 V
Battery capacity	550 mAh
Battery technology	Nickel-Metal Hydride (NiMH)
Number of batteries supported	3
Internal memory	32 MB
Specific absorption rate (SAR) value (EU)	2 W/kg
