56
Network Camera User Manual
Appendix 2 Specifications
Specification /Model
2MP ANPR Box Network Camera
Camera
Image Sensor
1/2.8＂CMOS
Image Size
1920×1080
Electronic Shutter
1/25s~1/100000s
Iris Type
DC Iris
Min. llumination
Color: 0.0026 lux@F1.2, AGC ON
Lens Mount
CS
Day&Night
ICR
WDR
120dB
Digital NR
3D DNR
Video Compression
H.265S/H.265+/H.265/H.264S/H.264+/H.264/MJPEG
H.264 Type
Baseline profile/main profile/high profile
Video Bit Rate
64Kbps~6Mbps
Resolution
1080P (1920×1080), 720P(1280×720), D1, CIF, 480×240
Main Stream
60Hz: 1080P/720P(1~30fps); 50Hz: 1080P/720P (1~25fps)
HFR mode: 1080P/720P(1~60fps); 50Hz: 1080P/720P (1~50fps)
Sub Stream
60Hz: 720P/D1/CIF/480×240 (1~30fps); 50Hz: 720P/D1/CIF/480×240 (1~25fps)
Third Stream
60Hz: CIF/ D1/480×240 (1~30fps); 50Hz: CIF/D1/ 480×240 (1~25fps)
Image Settings
BLC, HLC, Defog, Saturation, Brightness, Chroma, Contrast, Smart IR,Wide Dynamic,
Sharpen, NR, etc. adjustable through client or web browser
ROI
Support
Interfaces
Network
RJ45
Auido
1CH audio input; 1CH audio output; 1CH MIC IN
Reset
Yes
RS485
Yes
Storage
Built-in micro SD card storage slot, up to 128 GB
Alarm
2CH Alarm input; 2CH Alarm Ouput
USB
Yes
ABF
Yes
Fucntion
Remote Monitoring
Web browser, CMS remote control
Online Connection
Support simultaneous monitoring for up to 10 users and multi-stream transmission
Network Protocol
IPv4, IPv6, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP, SNMP, HTTP, HTTPS,
802.1x, QoS
Interface Protocol
ONVIF
Storage
Network remote storage, micro SD card storage
Smart Alarm
Motion detection, Sensor detection, SD card Full, SD card error, IP address conflict, cable
disconnection, scene change detection, video blur detection, video color cast detection,
ANPR
Power
AC24V/DC12V/PoE
Power Consumption
< 6.5W
Opterating
Environment
Temperature: -30°C~60°C; Relative Humidity: less than 95% (non-condensing)
Dimension (mm)
146.9×79×64
Weight（net）
Approx. 0.65KG
Installation
Wall mounting; ceiling mounting
