Advanced Data Formatting 14 - 9

Criteria

Code Types

Select all code types to be affected by the rule. Scan all selected codes in succession, before selecting other

criteria. To select all code types, don't select any code types.

Code 39

Codabar

61325

GS1 DataBar-14

GS1 DataBar Limited

Code 128

GS1 DataBar Expanded
