Motorola MC3190 User Manual

3
RetailData Icon
6. You will now have to calibrate your touchscreen and stylus by tapping the screen on the
crosshairs. Follow the instructions on the screen. After calibrating, press Enter to continue.
7. The reboot is NOT complete yet!!! The handheld will display a Windows desktop however the
reboot program is still running.
8. BE PATIENT!!! After about 2 or 3 minutes the handheld screen will change and will display a
Warm Boot message. You may see a list of files scroll by. This is normal.
9. The reboot is complete when the desktop includes a RetailData icon . This is the collection
program but the setup is NOT complete.
10. You will need to set your handheld’s internal date and time.
Double tap on the time in the lower right corner to bring up the
date/time settings.

Motorola MC3190 Specifications

General

Connectivity	802.11a/b/g, Bluetooth
Keypad	28-key numeric, 38-key shifted alpha, 48-key alphanumeric
IP Sealing	IP54
Processor	Marvell PXA320
Operating System	Windows CE 6.0 or Windows Embedded Handheld 6.5
Display	QVGA (320 x 240)
Battery	4800 mAh
Scanner	1D Laser or 2D Imager
Operating Temperature	-10° C to 50° C
Dimensions	190 mm x 82 mm x 145 mm
Drop Specification	Multiple 4 ft./1.2 m drops per MIL-STD 810G
