10-49 Chapter 10: Digrams and Parts Lists
December 6, 2004 68P81083C20-D
Controller Parts List for 800 MHz / 900 MHz
Reference
Symbol
MOTOROLA
Part Number Description
800 15/35W Specific (A)
900 12/30W Specific (B)
Capacitor, Fixed:
unless otherwise stated
C0100 2113743K15 0.10uF
C0102 2113743K15 0.10uF
C0104 2113743K15 0.10uF
C0105 2311049A42 3.3uF
C0106 2113930F67 470pF
C0107 2311049A07 1.0uF
C0108 2113743K15 0.10uF
C0109 2113741F49 0.010uF
C0110 2113741F49 0.010uF
C0200 2113743A23 0.22uF
C0201 2113743K15 0.10uF
C0202 2113743F08 0.22uF
C0203 2113741A57 0.033uF
C0204 2311049J11 4.7uF
C0205 2311049A09 2.2uF
C0206 2311049A07 1.0uF
C0207 2311049A07 1.0uF
C0208 2113741F49 0.010uF
C0209 2311049A01 0.10uF
C0210 2113743K15 0.10uF
C0211 2113743K15 0.10uF
C0212 2113741F49 0.010uF
C0213 2311049J23 10uF
C0214 2113743A19 0.10uF
C0215 2311049J23 10uF
C0216 2113743K15 0.10uF
C0217 2113743F08 0.22uF
C0218 2113743A19 0.10uF
C0219 2311049J26 10uF
C0221 2113743A19 0.10uF
C0222 2311049J26 10uF
C0223 2113741A53 22nF
C0224 2113741A53 22nF
C0225 2113743K15 0.10uF
C0226 2113741F17 470pF
C0228 2113743K15 0.10uF
C0229 2113740F39 33pF
C0230 2113743K15 0.10uF
C0231 2113743K15 0.10uF
C0234 2113743K15 0.10uF
C0235 2311049A07 1.0uF
C0236 2113741F13 330pF
C0237 2311049A42 3.3uF
C0240 2113741A57 0.033uF
C0241 2109720D14 0.1uF
C0242 2113741A33 3300pF
C0243 2113741F49 0.010uF
C0245 2109720D14 0.1uF
C0250 2113743A19 0.10uF (B)
C0251 2113741F17 470pF (B)
C0252 2113741F17 470pF (B)
C0253 2311049A04 0.33uF (B)
C0254 2113741F49 0.010uF (B)
C0255 2311049A42 3.3uF (B)
C0256 2311049A42 3.3uF (B)
C0257 2113741F49 0.010uF (B)
C0258 2311049A04 0.33uF (B)
C0260 2113743K15 0.10uF (B)
C0261 2113743K15 0.10uF (B)
C0262 2113743A19 0.10uF (B)
C0263 2113741A33 3300pF (B)
C0264 2113741A33 3300pF (B)
C0265 2113743K15 0.10uF (B)
C0266 2113743K15 0.10uF (B)
C0267 2113741A33 3300pF (B)
C0274 2113741F49 0.010uF (B)
C0401 2113740F36 24pF
C0402 2113740F36 24pF
C0403 2113930F67 470pF
C0404 2113740F36 24pF
C0405 2113740F39 33pF
C0406 2113740F39 33pF
C0407 2113930F67 470pF
C0408 2113930F67 470pF
C0409 2113930F67 470pF
C0410 2113930F67 470pF
C0411 2113930F67 470pF
C0412 2113930F67 470pF
C0413 2113743K15 0.10uF
C0414 2113930F67 470pF
C0415 2113930F67 470pF
C0416 2113930F67 470pF
Reference
Symbol
MOTOROLA
Part Number Description
C0417 2113741F25 1000pF
C0418 2113930F67 470pF
C0419 2113741F25 1000pF
C0420 2113741F25 1000pF
C0421 2113930F67 470pF
C0422 2113930F67 470pF
C0423 2113930F67 470pF
C0424 2113741F25 1000pF
C0425 2113930F67 470pF
C0426 2113930F67 470pF
C0427 2113930F67 470pF
C0428 2113930F67 470pF
C0429 2113930F67 470pF
C0430 2113930F67 470pF
C0431 2113930F67 470pF
C0432 2113741F25 1000pF
C0433 2113741F25 1000pF
C0434 2113930F67 470pF
C0435 2113930F67 470pF
C0436 2113930F67 470pF
C0437 2113740F39 33pF
C0438 2113930F67 470pF
C0439 2113930F67 470pF
C0440 2113930F67 470pF
C0441 2113930F67 470pF
C0442 2113741F49 0.010uF
C0443 2113741F25 1000pF
C0444 2113930F67 470pF
C0445 2113741F25 1000pF
C0446 2113741F49 0.010uF
C0447 2113930F67 470pF
C0449 2113741F49 0.010uF
C0450 2113930F67 470pF
C0451 2113741F49 0.010uF
C0452 2113741F49 0.010uF
C0453 2113930F67 470pF
C0454 2113741F49 0.010uF
C0456 2113930F67 470pF
C0457 2113741F49 0.010uF
C0458 2113741F49 0.010uF
C0459 2113930F67 470pF
C0460 2113741F49 0.010uF
C0461 2113741F49 0.010uF
C0462 2113930F67 470pF
Reference
Symbol
MOTOROLA
Part Number Description
C0463 2113741F49 0.010uF
C0464 2113930F67 470pF
C0465 2311049A07 1.0uF
C0467 2113741F17 470pF
C0468 2113741F25 1000pF
C0469 2113740F36 24pF
C0470 2113930F36 24pF
C0471 2113741F25 1000pF
C0472 2113930F36 24pF
C0473 2113931F49 0.010uF
C0500 2109720D14 0.1uF
C0501 2380090M24 10uF
C0502 2113741A45 0.010uF
C0503 2311049J44 47uF
C0504 2109720D14 0.1uF
C0505 2109720D14 0.1uF
C0506 2380090M24 10uF
C0507 2113740F51 100pF
C0508 2311049A97 33uF
C0509 2109720D14 0.1uF
C0510 2113743K15 0.10uF
C0511 2311049A07 1.0uF
C0512 2113743K15 0.10uF
C0513 2311049A07 1.0uF
C0514 2113743K15 0.10uF
C0518 2311049A07 1.0uF
C0550 2113740F41 39pF
C0551 2113740F41 39pF
C0552 2113740A55 100pF
C0553 2113740F41 39pF
C0554 2113740F41 39pF
C0555 2113740F41 39pF
C0556 2113740F41 39pF
C0557 2113740F41 39pF
C0558 2113740F41 39pF
C0559 2113740F42 43pF
C0561 2113740F41 39pF
C0562 2113740F41 39pF
C0564 2113740F41 39pF
C0565 2113740F41 39pF
C0566 2113740F41 39pF
C0568 2113743A19 0.10uF
C0569 2311049A01 0.10uF
C0570 2113743K15 0.10uF
Reference
Symbol
MOTOROLA
Part Number Description
