Chapter 10: Digrams and Parts Lists 10-50
68P81083C20-D December 6, 2004
C0572 2113743K15 0.10uF
C0575 2113740F41 39pF
C0999 2113741F37
Diodes: (See Note 1)
CR0105 4813833C02 Dual
CR0500 4813833C02 Dual
CR0510 4813833C02 Dual
CR0511 4813833C02 Dual
CR0550 4813833C02 Dual
CR0551 4813833C02 Dual
Connectors, receptacle:
J0401 0913915A18 25 LOPRO Female (A)
J0403 2805429W03 25 PINS, sealed
J0405 0905904V03 18 PINS, female
Coils: RF
L0200 2462587K26 33uH CHIP 10%
Transistors: (See Note 1)
Q0100 4880048M01 NPN 47K/47K
Q0103 4805921T09 FMG8
Q0200 4813824A10 NPN
Q0202 4880048M01 NPN 47K/47K
Q0400 4813824A17 PNP
Q0401 4813824A10 NPN
Q0402 4813824A17 PNP
Q0406 4813824A17 PNP
Q0407 4813824A10 NPN
Q0408 4813824A17 PNP
Q0409 4813824A10 NPN
Q0414 4880048M01 NPN 47K/47K
Q0416 4880048M01 NPN 47K/47K
Q0417 4880141L02 NPN
Q0418 4880048M01 NPN 47K/47K
Q0419 4880141L02 NPN
Q0420 4880048M01 NPN 47K/47K
Q0421 4880141L02 NPN
Q0422 4880048M01 NPN 47K/47K
Q0423 4880141L02 NPN
Q0424 4880048M01 NPN 47K/47K
Q0425 4880048M01 NPN 47K/47K
Q0426 4880048M01 NPN 47K/47K
Reference
Symbol
MOTOROLA
Part Number Description
Q0428 4805128M12 NPN
Q0429 4805128M27 BSR33
Q0430 4880141L02 NPN
Q0431 4880048M01 NPN 47K/47K
Q0432 4805128M12 NPN
Q0500 4813824A10 NPN
Q0510 4880048M01 NPN 47K/47K
Q0511 4805718V02 Pwr FET Audio P_CHAN
Q0513 4880048M01 NPN 47K/47K
Q0514 4880048M01 NPN 47K/47K
Q0515 4880048M01 NPN 47K/47K
Q0516 4880048M01 NPN 47K/47K
Q0517 4880048M01 NPN 47K/47K
Q0518 4880048M01 NPN 47K/47K
Q0519 4813824A10 NPN
Q0551 4813824A10 NPN
Q0552 4882033T01 NPN 10K/47K
Q0553 4805128M27 BSR33
Q0554 4802081B50 NPN DIG 47K/47K
Q0555 4813824A10 NPN
Q0556 4813824A10 NPN
Resistors, Fixed: ¾ unless
otherwise stated:
R0004 0662057A57 2.2K
R0046 0662057A73 10K
R0100 0662057B47 0
R0101 0662057A81 22K
R0104 0662057A81 22K
R0105 0662057A97 100K
R0106 0662057A73 10K
R0110 0662057A97 100K
R0111 0662057B47 0
R0112 0662057A73 10K
R0113 0662057B47 0
R0114 0662057A73 10K
R0115 0662057A73 10K
R0116 0662057A73 10K
R0117 0662057A97 100K
R0118 0662057A73 10K
R0119 0662057A56 2.0K
R0121 0662057B47 0
R0122 0662057B47 0
R0124 0662057B47 0
Reference
Symbol
MOTOROLA
Part Number Description
R0125 0662057B47 0
R0126 0662057A89 47K
R0127 0662057B47 0
R0129 0662057B47 0
R0130 0662057B47 0
R0131 0662057B47 0
R0132 0662057B47 0
R0200 0662057R92 47K
R0202 0662057A73 10K
R0204 0662057A89 47K
R0206 0662057A73 10K
R0207 0662057A73 10K
R0208 0662057A73 10K
R0209 0662057A73 10K
R0210 0662057A73 10K
R0211 0662057A73 10K
R0212 0662057A69 6.8K
R0213 0662057A69 6.8K
R0214 0662057A69 6.8K
R0215 0662057A49 1.0K
R0216 0662057A69 6.8K
R0217 0662057B05 200K
R0218 0662057B05 200K
R0219 0662057B05 200K
R0220 0662057A49 1.0K
R0221 0662057B05 200K
R0222 0662057A25 100
R0223 0662057A49 1.0K
R0224 0662057A41 470
R0228 0662057A69 6.8K
R0229 0662057A41 470
R0230 0662057A49 1.0K
R0231 0662057A25 100
R0233 0662057B47 0
R0234 0662057A65 4.7K
R0235 0662057A49 1.0K
R0236 0662057A81 22K
R0237 0662057A73 10K
R0238 0662057B02 150K
R0239 0662057A73 10K
R0244 0662057A65 4.7K
R0245 0662057A73 10K
R0250 0662057G13 100K (B)
R0251 0662057A81 22K (B)
Reference
Symbol
MOTOROLA
Part Number Description
R0252 0662057R92 47K (B)
R0253 0662057A53 1.5K (B)
R0254 0662057G13 100K (B)
R0255 0662057R30 1.0K (B)
R0256 0662057R60 10K (B)
R0257 0662057A97 100K (B)
R0300 0662057B47 0
R0400 0662057A73 10K
R0401 0662057A89 47K
R0402 0662057A81 22K
R0403 0662057A29 150
R0404 0662057A29 150
R0406 0662057A73 10K
R0407 0662057A41 470
R0408 0662057A73 10K
R0409 0662057A57 2.2K
R0410 0662057A25 100
R0411 0662057A25 100
R0412 0662057A41 470
R0413 0662057A73 10K
R0414 0662057A81 22K
R0415 0662057A57 2.2K
R0416 0662057A84 30K
R0417 0662057A97 100K
R0421 0662057A65 4.7K
R0422 0662057A63 3.9K
R0423 0662057A89 47K
R0424 0662057A65 4.7K
R0425 0662057A41 470
R0426 0662057A65 4.7K
R0427 0662057A32 200
R0428 0662057A89 47K
R0429 0662057A81 22K
R0430 0662057A73 10K
R0431 0662057A65 4.7K
R0432 0662057C01 0
R0433 0662057A89 47K
R0434 0662057A87 39K
R0435 0662057A73 10K
R0436 0662057A73 10K
R0437 0662057A65 4.7K
R0439 0662057A89 47K
R0440 0662057A73 10K
R0442 0662057A65 4.7K
Reference
Symbol
MOTOROLA
Part Number Description
To Next Page
