10-51 Chapter 10: Digrams and Parts Lists
December 6, 2004 68P81083C20-D
Notes:
1. For optimum performance, diodes, transistors and integrated
circuits must be ordered by MOTOROLA part numbers.
2. When ordering quartz crystal units or ceramic resonators,
specify carrier frequency, crystal (or resonator) frequency, and
crystal (or resonator) type number.
R0443 0662057A89 47K
R0444 0662057A73 10K
R0445 0662057A65 4.7K
R0446 0662057A73 10K
R0447 0662057A89 47K
R0448 0662057A73 10K
R0449 0662057A65 4.7K
R0450 0662057A73 10K
R0451 0662057A65 4.7K
R0452 0662057A73 10K
R0453 0662057A65 4.7K
R0454 0662057A73 10K
R0455 0662057A89 47K
R0456 0662057A73 10K
R0457 0662057A65 4.7K
R0458 0662057A73 10K
R0459 0662057A89 47K
R0460 0662057A73 10K
R0464 0662057A73 10K
R0465 0662057A53 1.5K
R0466 0662057A59 2.7K
R0467 0662057A65 4.7K
R0468 0662057A65 4.7K
R0469 0662057C01 0
R0473 0662057A73 10k
R0474 0662057A73 10k
R0475 0662057A66 5.1k
R0476 0662057A49 1.0k
R0500 0662057A73 10K
R0501 0662057A81 22K
R0502 0662057A69 6.8K
R0503 0662057R55 7.5K
R0504 0662057R31 0
R0505 0662057A65 4.7K
R0506 0662057A65 4.7K
R0511 0662057A43 560
R0512 0662057B05 200K
R0513 0662057B05 200K
R0514 0662057B02 150K
R0518 0662057A65 4.7K
R0519 0662057A81 22K
R0521 0662057A81 22K
R0522 0662057A81 22K
R0523 0662057A73 10K
Reference
Symbol
MOTOROLA
Part Number Description
R0525 0662057A65 4.7K
R0526 0662057A73 10K
R0527 0662057A73 10K
R0528 0611072A35 270
R0529 0662057B47 0
R0530 0662057R92 47K
R0531 0662057R54 6.81K
R0532 0662057R92 47K
R0533 0662057R92 47K
R0534 0662057B47 0
R0535 0662057A65 4.7K
R0536 0662057B47 0
R0546 0662057B47 0
R0547 0662057G13 100K
R0548 0662057R60 10K
R0549 0662057G33 237K
R0550 0662057A97 100K
R0551 0662057R92 47k
R0552 0662057A80 20k
R0553 0662057A81 22K
R0554 0662057A81 22K
R0556 0662057A25 100k
R0557 0662057R30 1.0K
R0558 0660076E83 27K
R0559 0662057R55 7.5K
R0560 0660076E83 27K
R0564 0662057A59 2.7K
R0566 0662057A73 10K
R0567 0662057R92 47K
R0568 0662057A65 4.7K
R0569 0662057R92 47K
R0570 0662057B47 0
R0571 0662057A42 510
R0572 0662057A97 100K
R0573 0662057A46 750
R0574 0662057A73 10K
R0576 0662057R92 47K
R0577 0662057B47 0
R0578 0662057A65 4.7K
R0579 0662057A65 4.7K
R0580 0662057A65 4.7K
R0581 0662057A61 3.3K
R0582 0662057R92 47K
R0583 0662057G13 100K
Reference
Symbol
MOTOROLA
Part Number Description
R0584 0662057A89 47K
R0586 0662057A49 1.0K
R0587 0662057A75 12k
R0588 0662057A89 47K
R0589 0662057G33 237K
R0590 0662057A81 22K
R0591 0662057A65 4.7K
R0592 0662057A61 3.3K
R0593 0662057A81 22K
R0594 0662057A61 3.3K
R0595 0662057A65 4.7K
R0596 0662057B47 0
R0598 0662057R60 10K
R0599 0662057A97 100K
R0800 0662057B47 0 (A)
R0900 0662057B47 0 (B)
Integrated Circuits:
(See Note 1)
U0101 5185748L01 32k x 8 sram
U0103 5113802A75 Microprocessor
U0104 5185765B30 Support Logic IC
U0105 5113806A20 Mux/demux Triple 2-ch
U0106 5105625U22 Flash 1mx8
U0108 5105109Z72 32k x 8 EEPROM ‘TSOP’
U0200 5185765B33 ASFIC
U0201 5113819A04 Quad Op Amp
U0202 5113819A04 Quad Op Amp
U0203 5109699X01 Audio Pwr Amp
U0250 5105835U50 Hear Clear (B)
U0400 5184704M61 Analog Switch 140016b
U0401 5113818A03 Op Amp
U0500 5105625U96 5v Reg
U0501 5105625U97 9.3v Reg
U0502 5113816A04 78l08 Soic 8v Reg
U0510 5105625U26 Dual 555 Timer
U0550 5113819A04 Quad Op Amp
U0551 5113811G02 D To A Mc144111dw
Zener diodes:(See Note 1)
VR0001 4813830A14 5.1V
VR0100 4813830A27 14V
VR0405 4813830A15 5.6V
VR0406 4813830A27 14V
Reference
Symbol
MOTOROLA
Part Number Description
VR0407 4813830A27 14V
VR0409 4813830A27 14V
VR0410 4813830A27 14V
VR0413 4813830A15 5.6V
VR0414 4813830A15 5.6V
VR0415 4813830A15 5.6V
VR0416 4813830A33 20V
VR0417 4813830A27 14V
VR0418 4813830A27 14V
VR0419 4813830A23 10V
VR0420 4813830A23 10V
VR0421 4813830A23 10V
VR0422 4813830A23 10V
VR0424 4813830A27 14V
VR0425 4813830A40 33V
VR0426 4813830A27 14V
VR0427 4813830A27 14V
VR0428 4813830A23 10V
VR0429 4813830A27 14V
VR0430 4813830A27 14V
VR0431 4813830A15 5.6V
VR0511 4813830A27 14V
Non-referenced Items:
SH0001 0705892W01 Digital Area Shield (A)
Reference
Symbol
MOTOROLA
Part Number Description
To Next Page
