December 6, 2004 68P81083C20-D
5-22 Disassembly & Reassembly and Replacement Procedures: Replaceable Pushbuttons Replacement Procedure
A A White Black 3805230Z42 3805231Z42 3805232Z42 N/A 3886267A40
B B White Black 3805230Z43 3805231Z43 3805232Z43 N/A 3886267A41
C C White Black 3805230Z44 3805231Z44 3805232Z44 N/A 3886267A42
Call Call White Black 3805230Z21 3805231Z07 3805232Z13 N/A 3886267A13
D D White Black 3805230Z45 3805231Z45 3805232Z45 N/A 3886267A43
Del Delete White Black 3805230Z35 3805231Z35 3805232Z35 N/A 3886267A14
Dim Dim White Black 3805230Z12 3805231Z17 3805232Z14 N/A 3886267A15
Dir Dir White Black 3805230Z38 3805231Z38 3805232Z38 N/A 3886267A36
Emer Emergency White Orange 3805230Z22 3805231Z09 3805232Z15 N/A 3886267A16
Emer Emergency Orange Black 3805230Z20 3805231Z16 3805232Z12 N/A 3886267A12
H/L Horn/Light White Black 3805230Z23 3805231Z04 3805232Z16 N/A 3886267A17
Home Home White Black 3805230Z10 3805231Z18 3805232Z03 N/A 3886267A18
Menu Menu White Black 3805230Z09 3805231Z19 3805232Z04 N/A 3886267A05
Mess Message White Black 3805230Z46 3805231Z46 N/A N/A N/A
Mon Monitor White Black 3805230Z33 3805231Z33 3805232Z33 N/A 3886267A19
Mpl Mpl White Black 3805230Z41 3805231Z41 3805232Z41 N/A 3886267A39
Opt Option White Black 3805230Z05 3805231Z20 3805232Z02 N/A 3886267A20
Page Page White Black 3805230Z03 3805231Z08 3805232Z17 N/A 3886267A21
Phon Phone White Black 3805230Z24 3805231Z05 3805232Z18 N/A 3886267A22
Pwr Power White Black 3805230Z39 3805231Z39 3805232Z39 N/A 3886267A37
Read Read White Black 3805230Z48 3805231Z48 N/A N/A N/A
Rcl Recall White Black 3805230Z36 3805231Z36 3805232Z36 N/A 3886267A34
S Menu Sym- White Black 3805230Z16 3805231Z21 3805232Z06 N/A 3886267A08
Scan Scan White Black 3805230Z25 3805231Z06 3805232Z19 N/A 3886267A23
Sec Secure White Black 3805230Z34 3805231Z34 3805232Z34 N/A 3886267A24
Sel Select White Black 3805230Z08 3805231Z22 3805232Z05 N/A 3886267A06
Site Site White Black 3805230Z37 3805231Z37 3805232Z37 N/A 3886267A35
Srch Search White Black 3805230Z11 3805231Z23 3805232Z20 N/A 3886267A25
Stat Status White Black 3805230Z47 3805231Z47 N/A N/A N/A
Sys System White Black 3805230Z40 3805231Z40 3805232Z40 N/A 3886267A38
Zone Zone White Black 3805230Z02 3805231Z24 3805232Z21 N/A 3886267A26
Call Symbol White Black 3805230Z26 3805231Z13 3805232Z22 N/A 3886267A07
Graphic Color Pushbutton Part Number
Legend Description Button Graphic Size A Size B Size C Size D Size E
