2.3.2InstallingtheBattery
2Turnclockwiseuntilsnug.Donotforce.
Useonlytheantennaintendedfortheradio.Makesurethattheantennahasanoperatingfrequency
engravingandabrightorangeo-ringatthebottomofthethread.Useofotherantennascanresultin
signicantrangelossduetopoorRFperformance.
2.3.2InstallingtheBattery
ProcedureSteps
1Removethebatteryfromitsprotectiveclearplasticcase.
2Insertthebatterytopintothecompartmentasillustrated.
3Carefullypressthebatterybottomdownwarduntilitclicksintoplace
-
2-3
