3-10 MAINTENANCE
5.6 Control Top Disassembly
1. To remove the control top assembly, place a screwdriver next to the antenna boss, and pry it
against the top escutcheon. This will lift the top escutcheon away from the top of the front
housing.
2. Remove the control top seal and transmit light pipe.
6.0 Radio Reassembly Ñ Detailed
6.1 Control Top Reassembly
1. Replace transmit light pipe and control top seal.
2. Peel off the liners from a new top adhesive, and place it in the recess in the front cover. Press
the top escutcheon down uniformly.
6.2 PTT Reassembly
1. Put the PTT seal in the PTT bezel.
2. Place the bezel ÔTÕ tab in the ÔTÕ slot inside the front cover PTT opening. Slightly slide down
the bezel so that the two snaps can be aligned and inserted into the two rectangular slots.
3. Press the PTT assembly against the front cover opening.
6.3 Speaker Reassembly
1. Align the notch in the speaker at the six oÕclock position with the tab on the front cover.
2. Place the speaker retainer bracket into the hole on the top of the front cover, and bend the
retainer down to Þt underneath the boss below the speaker.
NOTE
Look inside the front cover to make sure the T-tab and snaps are fully engaged with the front
cover.
