Chapter 4
PERFORMANCE TESTING
1.0 Introduction
The radios have been prepared to meet published speciÞcations through their manufacturing
process, with the use of laboratory-quality test equipment of highest accuracy. The recommended
Þeld service equipment approaches the accuracy of the manufacturing equipment with a few
exceptions.
Accuracy of the equipment must be maintained in compliance with the manufacturerÕs
recommended calibration schedule.
2.0 Setup
Supply voltage can be connected from the battery eliminator. The equipment required for alignment
procedures is connected as shown in the Radio Alignment Test Setup diagram.
Initial equipment control settings should be as indicated in the following table and should hold for all
alignment procedures except as noted in Table 4-1.
Table 4-1 Initial Equipment Control Settings
Service Monitor Test Set Power Supply
Monitor Mode: Power Monitor Spkr set: A Voltage: 7.5Vdc
RF Attn: -70 Spkr/load:
Speaker
DC on/standby:
Standby
AM, CW, FM: FM PTT: OFF Volt Range: 10V
OÕscope Source: Mod
OÕscope Horiz: 10mSec/Div
OÕscope Vert: 2.5kHz/Div
OÕscope Trig: Auto
Monitor Image: Hi
Monitor BW: Nar
Monitor Squelch: mid CW
Monitor Vol: 1/4 CW
Current: 2.5A
