Motorola P Series User Manual

3-20 MAINTENANCE
11.0 Programming/Test Cable
Figure 3-17 Programming/Test Cable
Figure 3-18 Wiring of the Connectors
25 POSITION
FEMALE CONNECTOR
25 POSITION
MALE CONNECTOR
1,000mm
CABLE
1,000mmÓ
CABLE
P1
P2 P3
P2
25 ways Female “D” Connector
Components molded inside
1
5
24
7
20
8
15
16
9
47
ohm
33K
+
1UF,16V 5%
Orange
Blue
White
Spiral
Yellow
P1
2.5mm stereo and
3.5mm
1
2
5
3
4
3.5mm Tip
(Speaker +)
3.5mm
Sleeve
2.5mm Tip
(Microphone)
2.5mm
2.5mm
Center
P3
25 ways Male “D”
1
15
4
11
1
2
3
4
5
3.5mm mono
2.5mm stereo
