Motorola P Series User Manual

Mechanical View and Parts List 3-17
* Not Þeld replaceable
Item
Motorola
Part
Number
Description
1 See Chapter 7 Antenna
2 3680529Z01 Knob, Volume
3 3680530Z02 Knob, Frequency
4 1385620Z01
1385620Z02
Escutcheon, Top (16 Ch.)
Escutcheon, Top (4 Ch.)
5 3385703Z01 Label, Escutcheon
6 3280722Z01 Seal, Control Shaft
7 6185621Z01 Lightpipe, Tx
8 3385629Z02
3385630Z01
Label, Name (P040)
Label, Name (P080)
9 3885617Z01 Cap, Dust
10 1385619Z01 Bezel, Side Control
11 7585618Z01 Keypad, Side Control
12 1585616Z01
1585616Z02
Housing, Front (P040)
Housing, Front (P080)
13 1380649Z03
* Escutcheon, FM
14 7585623Z01 Keypad, Front
15 0104009J11 Keypad Board Assembly
16 5104949J08 Display Module
17 4285609Z01 Retainer Plate
18 8480475Z02 Flex, Keypad/Controller
19 3585606Z02 Felt, Speaker
20 5085962A02 Speaker
21 1480577C01 Boot, Microphone
22 5013920A04 Microphone
23 8485687Z01 Flex, Microphone
24 2113740A55 Cap, 100pF
25 0980727Z01 Connector, Wire
26 4285601Z01 Retainer, Speaker
27 1480724Z01 Insulator, Speaker
28 3980667Z01 Contact Finger
29 1585608Z01 Shroud, Jack
30 0304726J04 Screw
31 0104008J60
0104008J90
Ctrl/RF Bd Assembly (VHF)
Ctrl/RF Bd Assembly (UHF)
32 7580556Z01 Pad, Thermal
33 3280534Z01 Seal, Contact
34 3380564Z01 Label, Warning
35 7585706Z01 Pad, Chassis
36 3280536Z01 Gasket, O-ring
37 2780518Z03 Chassis
38 See Chapter 7 Battery
39 HLN9714
HLN9844.
Beltclip, large (2in. wide belt)
Beltclip, medium (1,5in.belt)
Item
Motorola
Part
Number
Description
